You can find the Status Bar (figure below) at the bottom of an analysis project, which presents you general information of the current project.
The name of your selected analysis mode and analysis profile are displayed at this place. You can click it to open the Analysis Profile Options dialog to configure settings. See Analysis Profile for more details.
The number of your selected adapters displays here, by clicking it, the Network Adapter dialog appears and allows to select adapters. See Choosing Network Adapter for more details.
If you check new or disable an adapter, Colasoft Capsa will clear the buffer and data to restart new capture. If necessary, you are recommended to save the packets in buffer to your hard disk before you make any change in the Network Adapter dialog.
Shows the filter information. Accept means the number of the Accept checkboxes you checked in the Filter dialog. The same as Reject. You can click it to open the Filter dialog to set filters. See Using Filters for details.
Shows how long the current project has been initiated.
Accepted number means Colasoft Capsa has accepted those packets and analyzed them.
Dropped number means those packets are failed to meet the filter criteria and are not analyzed by the program.
Mouse moved over a button of the Ribbon or item in the Menu, the tip of the focused item shows in the status bar. By default it shows Ready here.
An Alarm icon and three counters of triggered alarms show on the right of the Status Bar. You can click the Alarm Explorer button to open the Alarm Explorer window, see Alarm Explorer Window for more details.
|
